A high-performance ATX motherboard built for AMD Ryzen 7000–9000 series processors, combining powerful thermal solutions, next-gen connectivity, and gamer-friendly DIY features.
Key Features:
AMD B850 Chipset & AM5 Socket – Compatible with AMD Ryzen 9000, 8000, and 7000 Series processors for upgraded performance
DDR5 Memory Support – Four DIMM slots supporting up to 256 GB RAM; overclocked speeds up to 8200+ MT/s (OC)
Robust Power & Cooling (Frozr Guard) – Includes extended heatsinks, 7 W/mK MOSFET thermal pads, heavy VRM heat sinks, and Thermal design for efficient heat dissipation
Next‑Gen Connectivity – Supports PCIe 5.0 x16 graphics slot, Lightning Gen 5 x4 M.2 SSD, Wi‑Fi 7, 5 Gb LAN, and numerous high-speed USB (including 10 Gbps Type‑C/A) ports
EZ DIY Design – User-centric features like tool-free M.2 installs (Shield Frozr II), PCIe clip, EZ Antenna, and clearly marked debug LEDs make builds and troubleshooting simpler
Enhanced Reliability – Equipped with stainless steel I/O shield, Over-Current Protection (OCP), grounding power design, voltage protection (TVS), and solid pin connectors for durability and stability
Rich I/O and Storage – Offers three M.2 slots (PCIe 5.0 and 4.0 tiers), four SATA 6 Gb/s ports, HDMI/DisplayPort (for APUs), plus 7.1-channel audio
